Broadcom Avago AFBR-HUD500Z alternative Duplex POF Cable

Replacement for Broadcom Avago AFBR-HUD500Z UL VW-1 Rated RoHS compliant Duplex POF Cable,black PE sheath,1.0/2.2/4.4mm,0.18dB/M@650nm,500meters spool

Our DCVZ2-1000 PMMA Plastic Optical Fiber-POF Cable refers to the PMMA Plastic Optical Fiber jacketed with black flame-retardant PE sheath to protect the PMMA Fiber Core from harsh environment. The DCVZ2-1000 duplex POF cable is an cost-effective alterantive replacement for some well-known brands such as Broadcom Avagao AFBR-HUD500Z, Asahi TCF-1000PW POF dumplex Cable, HITRONIC J-V2Y(ZN)11Y POF dumplex Cable,Mitsubishi ESKA GHV4002 duplex POF Cables for short distance transmission within 100meters.

Simplex POF Cable benefits:

• 55% lower cost than well-known brands
• 50% less power to operate than copper
• 80% reduction of carbon dioxide than copper
• Universally compatible with the Broadcom Avago Versatile Link family of connectors and fiber optic components as transmitters and receivers
• 1mm POF available in 1 grade with 0.18 dB/m typical attenuation (-40°C to +85°C) @650nm
• Waterproof, moisture-proof, EMI free
• ROHS & UL certified

POF Simplex Cable Basic Properties:

• Configuration: Duplex
• Core Diameter: 1.0mm
• Core Material: PMMA (Polymethyl Methacrylate)
• Jacket Diameter: 2.2mm
• Jacket Material: Halogen-Free Flame Retardant PE (Polyethylene) – Black
• Numerical Aperture: 0.5
• Attenuation: 0.19 dB/m at 650 nm
• Operating Temperature Range: -55°C to 90°C
• UL VW-1 1581 Style No. 5238
• RoHS Compliant

POF Simplex Cable Application:

• Industrial Data Links for Factory Automation and Plant Control
• Intra-system Links; Board-to-board, Rack-to-rack
• Telecommunications Switching Systems
• Computer-to-peripheral Data Links, PC Bus Extension
• Proprietary LANs
• Digitalized Video
• Medical Instruments
• Reduction of Lighting and Voltage transient Susceptibility
• High Voltage Isolation
